Dishwasher Features

Your KitchenAid dishwasher may have some or all of these features.

ProScrub

Option Wash Area

The ProScrub

option wash area is located at the back of the lower

level rack and the front corners of the upper level rack.

NOTE: You must select the ProScrub

option to use this feature.

Make sure items do not interfere with the water feed tube, spray

arms, or the lower rack ProScrub spray jets.

■ Keep the last tine row in the back of the lower rack in the

60° angled position when using the ProScrub

option.

■ In the back of the lower rack, load pans, casserole dishes, etc.,

with the soiled surfaces facing the ProScrub Plus

spray jets,

and resting on the last row of tines in the angled position.

■ Only one row of items may face the ProScrub

spray jets.

Stacking, overlapping or nesting items will keep the ProScrub

spray jets from contacting all of the surfaces.

■ In the upper rack, place tall or oddly shaped glasses or bottles

in the front corners of the rack face down. It is best to load

these items in between rows of tines.

ProScrub

Trio (on some models)

Lower jets clean pans, casseroles, etc., with tough food soil to

eliminate the need for soaking and scrubbing of dirty, baked-on

dishes.

Upper rack has two spray zones in the front corners to reach into

deeper or oddly shaped items.

Silverware Basket

Use the slots in the covers to keep your

silverware separated for optimum wash.

There are specially designed slots (small

round holes) for chopsticks. Mix

silverware types to keep them separated.

Load knives down, forks up, and

alternate spoons, for best cleaning results.

NOTE: If your

silverware does not

fit into the

designated slots,

lift and slide the

covers off of the

silverware basket.

CULINARY CADDY

Utensil Basket

Use the utensil basket to hold specialty

cooking utensils (serving spoons,

spatulas, and similar items), or

overflow silverware items.

The basket hangs on the bottom rack

in the right-hand corner. Load the

basket while it is on the bottom rack or

remove the basket for loading on a

counter or table.

NOTE: Spin the spray arms. Be sure

items in the basket do not stop the

rotation of the spray arms.

SURE-HOLD

Cup and Stemware Holder

Fold down the extra shelf on the left-hand or right-hand side of the

mid level rack to hold additional cups, stemware or long items such

as utensils and spatulas.

NOTE: Remove the culinary tool basket(s) when washing tall

stemware or other tall items in the top rack.

FLEXI-FOLD DOWN™ Flexible Tines

The row of tines on the left-hand and

right-hand sides of the top rack can

be adjusted to make room for a

variety of dishes.

To adjust the fold-down tines:

1. Grasp the tip of the tine that is in

the tine holder.

2. Gently push the tine out of the

holder.

3. Lay the tines down, toward the

center of the rack.

NOTE: The bottom rack may also have 1 or 2 rows of flexible tines

located in the back of the rack. Follow the same instructions to

adjust.

SURE-HOLD

Light Item Clips

The light item clips hold lightweight plastic items

such as cups, lids, or bowls in place during

washing.

To move a clip:

1. Pull the clip up and off the tine.

2. Reposition the clip on another tine.

A. Back of dishwasher
